1. Cloud printing function can realize long-distance data transmission and can work at any position within the effective range;
2. Excellent heat dissipation performance can cope with large-volume printing;
3.The reprint function avoids loss of electronic delivery bill information and omissions during printing due to lack of paper;
4. After reopening the cover, the paper is automatically positioned, which can effectively avoid the trouble caused by misalignment of printing and waste of delivery bills;2. Excellent heat dissipation performance can cope with large-volume printing;
3.The reprint function avoids loss of electronic delivery bill information and omissions during printing due to lack of paper;
4. After reopening the cover, the paper is automatically positioned, which can effectively avoid the trouble caused by misalignment of printing and waste of delivery bills;5. It can print 4'' large delivery bills with higher compatibility.
Application: logistics, warehousing, retail, supermarkets, Drink shop / Tea shop.
Project | Parameter | |
Printing method | Thermal | |
Resolution | 203dpi | |
Maximum print width | 4.23''(108mm) | |
Maximum printing speed | 6 ips(150mm/s) | |
Print length | 0.79''-9.84''(20-250mm) | |
sensor | Seam mark detection, black mark detection, paper shortage detection, backflow detection, cover opening detection, head temperature detection | |
medium | type | Label paper, Bottom black mark, continuous paper, folding paper |
Width (label + backing paper) | 4.72''(120mm(MAX)) | |
Thickness (label + backing paper) | 0.0023''-0.0071''(0.06mm~0.18mm) | |
Maximum paper roll diameter | φ5.12''(φ130mm) | |
Reel inner diameter | φ1''(φ25.4mm), φ1.50''(φ38mm) | |
Paper tearing method | Manual tearing | |
processor | Arm Cortex-A7 core | |
storage | RAM | 256MB |
FLASH | 256MB | |
Function | button | Rocker switch, Feed button, Paper bin cover opening button |
Indicator Lights | YES | |
buzzer | Buzzer tone | |
Display | / | |
other | Automatic paper recognition, reprinting when out of paper, first sheet return, bad pixel detection | |
Communication interface | WU | |
programming language | TSPL | |
Built-in fonts | ASCll Font: 10x12, 14x20, 16x24, 24x32, 36x48, 14x19, 21x27, 14x25, 12x24 | |
GB18030: 24×24, 16x16 | ||
Code Page | Extended character table | CP437, CP850, CP852, CP860, CP863, CP865, CP866, WPC1250, WPC1251, WPC1252, WPC1253, WPC1254 |
Barcode | One-dimensional code | Code39, Code39C, CodeI25, Code93, ITF25, EAN128, Code128, Codabar, EAN-8, EAN8+2, EAN8+5, EAN -13, EAN13+2, EAN13+5, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPCE+5MSIC, ITF14, EAN14, Code11 |
QRCODE, PDF417 (optional) | ||
software | drive | XP, Win7, Win8, Win10, Win11, ios, Android, Linux, MacOS |
SDK | Android, iOS, Windows | |
Label design | Barcode label editing software (PC), APP | |
Power adapter | Input: AC 100-240V, 50/60Hz | |
Output: DC 24V/2.5A | ||
Environmental parameters | Work | Temperature: 32-104℉(0-40℃); Humidity: 20-90% (non-condensing) |
storage | Temperature: 14-140℉(-10-60℃); Humidity: 5-95% (non-condensing) | |
Physical parameters | Dimensions (length, width, height) | 217mm*182mm*172mm |
weight | 1.72kg | |
Accessories | Standard | Power cord, USB data cable, power adapter, quick installation guide |
Optional | External bracket |
